WS85 Skid Steer Loader


General specifications of WS85 skid steer loader

Engine

Mitsubisht S4S-DT

Rated power(kw)

62

Rated speed(rpm)

2500

External dimensions: length * width * high

3688*1817*2023(mm)

Operating weight(kg) with bucket

3867

Max travelspeed(km/h)

12

Performance

Rated operating capacity(kg)

1050

Tipping load(kg)

2100

Max.dump height(mm)

2543

Max.dump distance(mm)

652

Turn radlus,front tyre(mm)(without attachment)

1346

Wheel base(mm)

1179

Bucke capacity(m3)

0.52

Fuel tank capacity(m3)

88

Hydraulic oil tank capacity(m3)

70

Servo Control Configuration Table

Color

Body

Yellow

Operating Arm

Yellow

Back Cover

Yellow

Cab

Black

Attachment

Black

Cab

Air conditioner

Heater

Water-cooled engine

Fully enclosed drive cabin

Light

Work Light

Yes

Back-up Buzze

Yes

Interior Light

Yes

Hydraulic System

Pistion Pump

REXROTH
46cc

High Torque Motor

POCLAIN
398cc

Pilot Handle

Italy HYDE

Gear Pump

PERMCO 33cc

Leveling Valve

SAUER DANFOSS

Multi-way Valve

Italy HYDE

Solenoid Valve

SAUER DANFOSS



Engine

Mitsubisht S4S-DT
62KW/2500rpm

Bucket

Auto Balance

Control

Joystick Control

Quick-change Hanger

Universal

Brake

Motor With Brake

Seat

Safety Belt,
Operating Bumper

Solid Tire

12x16.5

Wiper

Yes

Attachment

Standard Bucket

Horn

Yes

Accelerator

Hands-feet
Double Control

Rear mirror

Yes

Auxiliary Hydraulic Control Device

G1 Output Fast Connection
G3/8 Oil-return Fast Connection

Loader Body

WS85

Oil Tube

24°International Standard

Operating Arm Support

Oil Cylinder Fixed Bracket

Hydraulic oil flow rate

82.5L/min


WS85 Skid Steer Loader 2017-7-10 This article has been read 1423 Secondary
